Frame assembly – Wellsaw 1016 User Manual
Page 15
1
155108
Back Blade Guard
Frame Assembly
2
100063
Thumb Screw
3
100034-001
Set Screw, 1/4-20 x 3/16 (2 req'd)
4
M-102
Sliding Weight Post
5
B-101
Sliding Weight Bar
6
100000-024
Machine Screw, RH, 1/4-20 x 3/8
7
100025-001
Lock Washer, 1/4
8
M-857
Sliding Weight Spring
9
M-807
Sliding Weight
10
100042-005
Thumb Screw, 3/8-16 x 2-1/2
11
100024-003
Wing Nut, 3/8-16
12
105321
Wheel Plate
13
100004-019
Cap Screw, HH, 5/16-18 x 1-1/8
14
100034-005
Set Screw, 5/16-18 x 3/4 (4 req'd)
15
100065-007
Hex Nut, 5/8-18
16
Rite Tension Assembly (see page 25)
17
100004-099
Cap Screw, HH, 5/16-18 x 2-1/4
18
100025-002
Lock Washer, 5/16
19
105348
Idle Wheel Guard
20
100013-010
Machine Screw, BH, 1/4-20 x 1/4
21
100004-015
Cap Screw, HH, 5/16-18 x 3/4
22
B-025
Handle
23
101456
Frame
24
105350
Drive Wheel Splash Guard
25
155120
Drive Wheel Guard
26
105428
Drive Wheel Assembly (includes items 28-35 and 7)
27
105429
Idle Wheel Assembly (includes items 31-36)
28
B-086
Internal Ring Gear
29
101574
Band Drive Wheel, 1" Blade
30
100004-068
Cap Screw, HH, 1/4-20 x 1-1/4 (6 req'd)
31
100019-016
Hex Jam Nut, 5/8-18
32
100068-002
Snap Ring
33
100414-003
Bearing
34
105415
Wheel Spacer
35
105421
Wheel Axle
36
101575
Band Idler Wheel, 1" Blade (includes items 32-34)
37
098005-039W Blade, Bi-Metal, 11'6" x 1" x .035, 5/8 TPI
38
100004-030
Cap Screw, HH, 3/8-16 x 1-1/2
39
100025-003
Lock Washer, 3/8
40
101548
Guide Bracket Beam
41
100169
Tube Clamp
42
100000-010
Machine Screw, RH, 8-32 x 5/16
44
100023-005
Hex Nut, nylon insert, 5/8-11
45
100008-018
Cap Screw, SH, 5/16-18 x 3/4
46
100004-084
Cap Screw, HH, 5/8-11 x 6
47
105756
Motor Mount Support
48
105753
Moter Mount
49
100023-005
Hex Nut, 5/8-11, Nylon Locking
50
100004-029
Cap Screw, HH, 3/8-16 x 1-1/4
51
100097-006
Washer, 13/32 ID x 2 OD
52
100133-004
Wire Brush Wheel
53
105757
Blade Brush Bracket
54
100039-003
Set Screw, SH, 1/4-20 x 5/8
55
100017-001
Hex Hut, Heavy, 1/4-20
56
155205-003
wing nut.
57
100017-003
Hex Nut, 3/8-16
58
155147
Arm
59
100406-001
Bearing
60
100030-005
Flat Washer, 3/8
62
155146
Blade Brush Assembly (includes items 50-52 and 57-60)
14
