PAGE 7
CHART 3
CHART 4
CHART 5
MOISTURE CONTENT OF GAS (LBS. H2O/MMSCF)
AFTER DEHYDRATOR WITH GASDRY PEAK
CHART 2
GASDRY PRIME CONSUMPTION RATE (LBS./MMSCF)
4.5-B GASDRY PEAK DESICCANT
This general purpose tablet is recommended for instal-
lations where inlet gas temperature is 80
O F or lower.
Depending on the pressure and temperature, GasDry
Peak can provide a residual moisture content below 7
#/MMSCF.
Chart 3 shows the level of dryness that GasDry Peak will
provide at different conditions.
Chart 4 shows an approximate consumption rate for
GasDry Peak at several conditions. Use the charts for
guidelines to calculate the approximate consumption
rate of the desiccant.
4.5-C GASDRY MAX DESICCANT
Where extremely dry gas is required or where operating
pressure is low, GasDry Max tablets provide a lower
residual moisture content.
Chart 5 shows the level of dryness that GasDry Max will
provide at different conditions.
Chart 6 shows an approximate consumption rate for
GasDry Max at several conditions. Use the charts for
guidelines to calculate the approximate consumption
rate of the desiccant.
MOISTURE CONTENT OF GAS (LBS. H2O/MMSCF)
AFTER DEHYDRATOR WITH GASDRY MAX
CHART 6
NOTE
MMSCF is 1,000,000 STANDARD CUBIC FEET
GASDRY MAX CONSUMPTION RATE (LBS./MMSCF)
1450
PSIG
4.6
4.0
3.5
3.0
2.6
2.2
1.9
1.7
1.4
1.2
1.0
INLET
TEMP
100 o F
95 o F
90 o F
85 o F
80 o F
75°F
70 o F
65°F
60 o F
55°F
50°F
100
PSIG
40.9
35.1
30.2
25.8
22.0
18.6
15.7
13.3
11.2
9.4
7.8
750
PSIG
7.4
6.4
5.6
4.8
4.1
3.5
3.0
2.6
2.2
1.8
1.6
1000
PSIG
6.0
5.2
4.5
3.9
3.3
2.9
2.4
2.1
1.8
1.5
1.3
1100
PSIG
5.6
4.8
4.2
3.6
3.1
2.7
2.3
2.0
1.7
1.4
1.2
1200
PSIG
5.2
4.6
4.0
3.4
2.9
2.5
2.2
1.9
1.6
1.3
1.1
1300
PSIG
5.0
4.3
3.8
3.2
2.8
2.4
2.1
1.8
1.5
1.3
1.1
1400
PSIG
4.7
4.1
3.6
3.1
2.7
2.3
2.0
1.7
1.4
1.2
1.0
1450
PSIG
8.6
7.4
6.3
5.4
4.7
4.0
3.4
2.8
INLET
TEMP
80 o F
75°F
70 o F
65°F
60 o F
55°F
50°F
45°F
100
PSIG
72.5
61.5
51.9
43.9
37.0
30.9
25.8
21.5
750
PSIG
13.6
11.6
9.9
8.4
7.2
6.0
5.1
4.3
1000
PSIG
11.0
9.4
8.1
6.9
5.9
5.0
4.2
3.6
1100
PSIG
10.3
8.8
7.6
6.5
5.5
4.7
4.0
3.3
1200
PSIG
9.7
8.3
7.1
6.1
5.2
4.4
3.8
3.2
1300
PSIG
9.2
7.9
6.8
5.8
5.0
4.2
3.6
3.0
1400
PSIG
8.8
7.6
6.5
5.5
4.8
4.0
3.4
2.9
1450
PSIG
7.9
6.8
5.8
5.0
4.3
3.7
3.1
2.6
INLET
TEMP
80 o F
75°F
70 o F
65°F
60 o F
55°F
50°F
45°F
100
PSIG
66.9
56.7
47.9
40.5
34.1
28.5
23.8
19.8
750
PSIG
12.5
10.7
9.1
7.8
6.6
5.6
4.7
4.0
1000
PSIG
10.1
8.7
7.4
6.4
5.4
4.6
3.9
3.3
1100
PSIG
9.5
8.2
7.0
6.0
5.1
4.3
3.7
3.1
1200
PSIG
9.0
7.7
6.6
5.6
4.8
4.1
3.5
2.9
1300
PSIG
8.5
7.3
6.3
5.4
4.6
3.9
3.3
2.8
1400
PSIG
8.1
7.0
6.0
5.1
4.4
3.7
3.2
2.7
1450
PSIG
6.0
5.2
4.5
3.9
3.4
2.9
2.5
2.1
1.8
1.6
1.3
1.1
0.9
INLET
TEMP
100 o F
95 o F
90 o F
85 o F
80 o F
75°F
70 o F
65°F
60 o F
55°F
50°F
45°F
40°F
100
PSIG
53.1
45.6
39.2
33.5
28.6
24.2
20.5
17.3
14.6
12.2
10.2
8.5
7.0
750
PSIG
9.7
8.4
7.2
6.2
5.3
4.6
3.9
3.3
2.8
2.4
2.0
1.7
1.4
1000
PSIG
7.8
6.7
5.8
5.0
4.3
3.7
3.2
2.7
2.3
2.0
1.7
1.4
1.2
1100
PSIG
7.3
6.3
5.5
4.7
4.1
3.5
3.0
2.5
2.2
1.8
1.6
1.3
1.1
1200
PSIG
6.8
5.9
5.1
4.4
3.8
3.3
2.8
2.4
2.1
1.7
1.5
1.2
1.1
1300
PSIG
6.4
5.6
4.9
4.2
3.6
3.1
2.7
2.3
2.0
1.7
1.4
1.2
1.0
1400
PSIG
6.1
5.3
4.6
4.0
3.5
3.0
2.5
2.2
1.9
1.6
1.4
1.1
1.0
1450
PSIG
13.4
11.6
10.1
8.7
7.5
6.5
5.6
4.8
4.1
3.5
3.0
2.5
2.1
INLET
TEMP
100 o F
95 o F
90 o F
85 o F
80 o F
75°F
70 o F
65°F
60 o F
55°F
50°F
45°F
40°F
100
PSIG
118.5
101.8
87.5
74.7
63.7
54.0
45.6
38.6
32.5
27.1
22.7
18.9
15.6
750
PSIG
21.5
18.6
16.1
13.9
11.9
10.2
8.7
7.4
6.3
5.3
4.5
3.8
3.2
1000
PSIG
17.3
15.0
13.0
11.2
9.7
8.3
7.1
6.1
5.2
4.4
3.7
3.1
2.6
1100
PSIG
16.2
14.0
12.2
10.5
9.0
7.8
6.6
5.7
4.8
4.1
3.5
2.9
2.5
1200
PSIG
15.2
13.2
11.5
9.9
8.5
7.3
6.3
5.4
4.6
3.9
3.3
2.8
2.3
1300
PSIG
14.4
12.5
10.9
9.4
8.1
7.0
6.0
5.1
4.4
3.7
3.2
2.7
2.2
1400
PSIG
13.7
11.9
10.4
8.9
7.7
6.6
5.7
4.9
4.2
3.5
3.0
2.6
2.1
GASDRY PEAK CONSUMPTION RATE (LBS./MMSCF)
