PARTS SECTION 11
11.3 DRYER REPLACEMENT PARTS
** Orifice union shipped without orifice plate drilled. Center of plate must be drilled with a 3/4" diameter hole.
ITEM
1
1a
1b
1c
2
3
4
5
6
7
8
8a
9
9a
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
40a
DESCRIPTION
Inlet Transfer Valve
Seat & Seal Kit for Inlet Transfer Valve
Position Indicator Kit for Inlet Transfer Valve
Shuttle Assembly Kit for Inlet Transfer Valve
Outlet Check Valve
Purge Exhaust Valve
Diffuser basket
Fill/Drain Plug
Stud
Gasket for 3" R.F. Flange
Purge Exhaust Muffler
Elements, for one purge exhaust muffler
Control Air Filter (includes element)
Element, control air filter
Control Pressure Regulator
Bushing w/Screen (for twr pressure sw conn)
Purge Metering Valve
Purge Orifice Union **
Purge Check Valve
Purge Pressure Gauge
Safety Relief Valve
Screen for Y-strainer
Regulator for Pre-Cooler Air Motor
Lubricator for Pre-Cooler Air Motor
Oil Muffler for Air Motor
Core for Pre-Cooler
Air Motor for Pre-Cooler
Fan for Pre-Cooler
Guard for Pre-cooler Fan
1/2" NPT Isolation Valve
Manual Drain (afterfilter)
PD-5 Differential Pressure Indicator
Separator/PreFilter Element
PreFilter Element
AfterFilter Element
Oil for Lubricator (quart)
Flushing Solvent for Pre-Cooler Air Motor
1-1/2" Victaulic Coupling
PDV-500T
1/8" NPT Pre-Cooler & PDV Manual Ball Valve
Outlet Ball Valve
Handle for Outlet Ball Valve
Temperature Gauge
Thermowell for Temperature Gauge
Desiccant
Activated Alumina, 1/8" dia., 350# drum
PART NO.
14-2709
26-0643
26-1054
26-1039
14-2576
14-2127
26-7167
14-1534
28-0413
18-0227
26-0366
26-5777
84-20106
26-10405
26-7655
14-1820
14-0933
14-1773
14-2627
29-0394
14-2577
26-7632
26-7501
26-7502
26-7721
34-0994
34-0926
26-7670
26-7671
14-2615
84-10852
84-10001
26-10041
26-2090
26-2112
26-7032
26-7157
12-2138
39-0284
14-2734
14-2753
14-2754
29-0108
29-0107
-
33-0401
QTY
1
1
1
1
2
2
2
4
4
18
2
4
1
1
1
2
1
1
2
1
2
1
1
1
1
1
1
1
1
3
1
3
1
1
1
1
1
5
1
3
1
1
1
1
-
6
FR-1600
11.4 HOW TO ORDER PARTS
To order parts contact your local VAN AIR representative, the representative that sold the dryer, or the factory.
When contacting your local VAN AIR representative or the factory, the following information is necessary:
Dryer model
Dryer serial number
Dryer part number
This information can be found on one of the dryer data tags. One is located on the outlet side aftercooler support and the other is located inside the
door of the control box.
The Service Department can be reached by calling 888-606-9303 or faxing 814-774-3482. Hours are 8:00 AM EST to 5:00 PM EST, M-F.
