Currency capacity depends upon the dispenser mechanism installed in the ATM, but is also affected by
note quality and thickness. Typical capacities are provided in the following table: DO NOT be tempted to
over fi ll the cassette.
The purpose of this section of the manual is to describe the procedures for cassette closing and replenish-
ment. Information concerning note handling and quality issues are explained where appropriate.
The dispensing mechanism delivers the appropriate number of notes from the note cassette to fulfi ll the
customer’s withdrawal request. The purpose of the reject area or cassette is to accept and hold notes that have
been transferred from the note cassette but not dispensed. Some situations that could cause the mechanism
to reject notes are:
(1) Multiple notes stuck together (2) Note width too short or long.
Other conditions that could cause a reject are described in the next section, Note Condition.
I
NTRODUCTION
D
ISPENSING
M
ECHANISMS
**CAUTION**
DO NOT RECYCLE REJECTED NOTES INTO A CASSETTE!
Doing so could cause more rejects and/or currency jams.
* PLEASE READ *
The Model RL1600 production units are equipped with the MiniMech dispenser.
Also, there will only be one style of cabinet offered which can accommodate the dispenser mentioned
above.
DISPENSER CASSETTE RECOMMENDED
MAXIMUM CAPACITY
REJECTED NOTE
CAPACITY
Minimech Single 750 Notes Less than 100
RL1600 DISPENSING MECHANISM
