2
© 2011. All rights reserved .
GENERAL INFORMATION
1. These pumps are equipped with an omni-directional
mechanical float switch. The pump will turn on
automatically when the water level in the basin
reaches approximately the float switch "on" level and
automatically turn off when the water is pumped down
to the fl oat switch "off" level. See Chart A for details.
2. The pit must be a minimum of 30" deep and 18" in
diameter. The pump requires a minimum diameter
of 18" so that the float switch will operate without
restriction. Any smaller diameter may restrict the
switch operation, resulting in pump failure.
INSTALLATION (See Figure 1)
1. For your safety, turn off the electrical power at the
service entrance to avoid any possible electrical
shock hazards. Electrical wiring and protection
must be in accordance with National Electrical Code
and any other applicable state and local electrical
requirements.
2. Install proper check valve, preferably just above the
basin to allow easy removal of the pump for cleaning
or repair.
3. All installations require a basin cover to prevent debris
from falling into the basin and to prevent accidental
injury.
4. Gas tight seals are required in all sewage installations
to contain gases and odors.
5. Vent gases and odors to the atmosphere through vent
pipe.
6. When a check valve is installed, drill a 3/16" dia. hole
in the discharge pipe even with the top of the pump.
NOTE: THE HOLE MUST ALSO BE BELOW THE
BASIN COVER AND CLEANED PE RI OD I CAL LY.
Water stream will be visible from this hole during pump
run periods.
7. Securely tape or clamp power cord to discharge pipe.
8. Use full-size discharge pipe.
9. Basin must be in accordance with applicable codes
and specifications.
10. Pump must be level and float mechanism clear of
sides of basin before starting pump.
11. Basin must be clean and free of debris after
installation.
12. Gate Valve or Ball Valve to be supplied by installer and
installed according to any and all codes.
13. Plug in pump and restore power at the service
entrance. Fill basin with water to check automatic
switch operation and adjust if necessary to prevent
switch from ‘hanging-up” and preventing proper pump
operation. Once proper operation is verified, install
basin cover
Pump On / Off Levels Chart A
Float Switch
Pump Model
50TC
On Level 14"
Off Level 9"
This product is warranted for one year from the date of purchase or two years
from the date of manufacture, whichever occurs first. Subject to the conditions
hereinafter set forth, the manufacturer will repair or replace to the original
consumer, any portion of the product which proves defective due to defective
materials or workmanship. To obtain warranty service, contact the dealer from
whom the product was purchased. The manufacturer retains the sole right and
option to determine whether to repair or replace defective equipment, parts or
components. Damage due to conditions beyond the control of the manufacturer is
not covered by this warranty.
THIS WARRANTY WILL NOT APPLY: (a) To defects or malfunctions resulting from
failure to properly install, operate or maintain the unit in accordance with printed
instructions provided; (b) to failures resulting from abuse, accident or negligence or
use of inappropriate chemicals or additives in the water; (c) to normal maintenance
services and the parts used in connection with such service; (d) to units which are
not installed in accordance with normal applicable local codes, ordinances and
good trade practices; and (e) the unit is used for purposes other than for what it
was designed and manufactured.
RETURN OF WARRANTED COMPONENTS: Any item to be repaired or replaced
under this warranty must be returned to the manufacturer at Kendallville, Indiana or
LIMITED WARRANTY
such other place as the manufacturer may designate, freight prepaid.
THE WARRANTY PROVIDED HEREIN IS IN LIEU OF ALL OTHER EXPRESS
WARRANTIES, AND MAY NOT BE EXTENDED OR MODIFIED BY ANYONE.
ANY IMPLIED WARRANTIES SHALL BE LIMITED TO THE PERIOD OF
THE LIMITED WARRANTY AND THEREAFTER ALL SUCH IMPLIED
WARRANTIES ARE DISCLAIMED AND EXCLUDED. THE MANUFACTURER
SHALL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES, SUCH AS, BUT NOT LIMITED
TO DAMAGE TO, OR LOSS OF, OTHER PROPERTY OR EQUIPMENT,
LOSS OF PROFITS, INCONVENIENCE , OR OTHER INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY TYPE OR NATURE. THE LIABILITY OF
THE MANUFACTURER SHALL NOT EXCEED THE PRICE OF THE PRODUCT
UPON WHICH SUCH LIABILITY IS BASED.
This warranty gives you specific legal rights, and you may have other rights which
vary from state to state. Some states do not allow limitations on duration of implied
warranties or exclusion of incidental or consequential damages, so the above
limitations may not apply to you.
WARRANTY VALID IN CANADA AND MEXICO.
