Page 16
© TrynEx International 2012 (REV B) F50735
16
Harness Diagram
Model # SP-9800X
D6514 Center High Mount Stop Lamp
F50562 Rectangle Work Light
F50408 Spreader Harness
Red
Black
Load View
IMPORTANT: Do Not modify harness length. Any modifications
will void warranty.
Special Notes:
1) All external connections must have dielectric grease.
2) Read lead labels before attaching to power source or ground.
3) No other devices may be spliced into wiring harness.
4) Any repairs to wiring harness must be done with heat shrink butt
connectors.
