Control Diagram
Model # SP-9800X
IMPORTANT: In the off season remove control
and put in a cool dry place. The interior
summer temperatures could damage circuit
board and void warranty.
F50543 Control Pendant
Control Module Parts
2
4
1
3
Key
Part No.
Description
Qty.
1
D6133
Bolt | 5/16”-18 X 1/2” Hex
4
2
D6553
Screw | #10 X 3/4”
4
3
F50488
Power Module Box
1
4
F50489
Power Module Box Cover
1
