AS-1785 Installation Guide P. 9
Caution! If multiple relays or modules are
connected to the GROUND OUT WHEN RUNNING
wire, make sure they are diode isolated from one
another: feedback may otherwise occur, causing
damage to the vehicle.
This input should be used in vehicles with negative-
switching Door pins or Dome Light circuits. Connect
to the Dome Light wire that tests ground when a Door
is open.
11 GREY
(–) Negative Door
input
Caution! The installer should use either the positive
or the negative Door input. Never use both of them
simultaneously.
It is essential that the Remote Car Starter be
connected in such a way as will allow each one of the
Doors to turn off Ready Mode: the driver-side Door
Pin does not constitute by itself a sufficient
connection.
12 YELLOW
(+) Glow-Plug
input
In Diesel Mode, this positive input will monitor the
Glow Plug Light: it will wait for up to 18 seconds
until the Glow-plug Light goes out before allowing
the Remote Car Starter to proceed to cranking the
Engine. Connect to the side of the Glow-plug Light
which is positive when the Light is on.
Note: the Remote Car Starter will nevertheless
proceed to cranking the Engine if the Glow-plug
Light is still on after the 18-sec. delay (25 sec.
when the Run Time is set to 30 min.).
A Note on the Diesel Glow-plug Indicator
Light:
