P. 4 Installation Guide AS-1785
♦ On vehicles equipped with daytime running
lights, the installer may be unable to see
certain programming results since the
daytime running lights never go out.
Note: The Parking Light Output Relay of the
unit gives two clicking sounds for each flash
of the lights: one click when the lights would
go
ON and one click when the lights would go
OFF .)
♦ Parking Light flashes to which the text
refers throughout this manual refer to the
Parking Light output of the unit, not of the
vehicle.
Harness Description
When connecting a Remote Car Starter, it is important to make sure that the connector with the
Ground wire is connected first, before making the 12-volt connections. Should the Unit be powered
up before being grounded, there could be serious damage to internal components of the Unit.
Be careful not to power up a Remote Car Starter before it is properly grounded. To avoid any
accident, it is recommended to pull out the Fuses from their sockets before the installation, and to
put them back during the very last steps.
6-Pin Main Ignition Harness
Wire Colour Function Description
Connect to the largest 12 V supply wire at the
Ignition Harness. Ensure that the OEM power
wire is fused for more than 30 A.
A RED (+) 12 V Battery
Please note: some of the most recent vehicles
have no suitable 12 V source at the Ignition
Switch (the 12 V wire is too small to supply the
necessary current). In such cases, it is
recommended to use the fuse box or the B+
connection on the Battery.
B PURPLE (+) Starter output
(30 A)
Connect to the Starter wire of the vehicle. The
source wire should have +12 V with the Ignition
Key in the CRANK position only.
Connect to the largest 12 V supply wire at the
Ignition Harness. Ensure that the OEM power
wire is fused for more than 30 A.
C RED (+) 12 V Battery
Please note: some of the most recent vehicles
have no suitable 12 V source at the Ignition
Switch (the 12 V wire is too small to supply the
necessary current). In such cases, it is
recommended to use the fuse box or the B+
connection on the Battery.
D YELLOW
(+) Ignition
output (30 A)
Connect to the Ignition wire of the vehicle. The
source wire should have +12 V with the Ignition
Key in the IGNITION ON (RUN) and CRANK
positions.
