P. 24 Installation Guide AS-1785
Diagnostics – Parking Light Flash Table
Flashes Description
1
• Doors locked, Starter Kill armed.
• End of Run Time.
• TRUNK button pressed
• Start signal received by the Remote Car Starter.
• Cold Weather Mode cancelled.
• Cannot start after maximum number of attempts is reached.
2
• Doors unlocked, Starter Kill disarmed.
• Remote start attempt cancelled by remote.
3
• Entering Cold Weather Mode.
• Entering or Exiting Ready Mode.
• Entering Extended Run Time.
4
• +12 V where detected on the brake line and cranking was cancelled.
• Entering Tach-programming Mode
5
• New Transmitter programmed.
• Tach programmed.
6
• A remote start was attempted while a Tach or a vacuum signal was detected
before cranking.
8 • Unit reset: occurs when the Unit is reset to the factory defaults.
10 • The Hood Switch line went to ground during cranking or Run Time.
1 – pause – 2 • There was an attempt to start the vehicle while the Remote Car Starter was
in Valet Mode.
2 – pause – 2 • There was an attempt to start the vehicle while the Remote Car Starter was
in Home Valet Mode.
4 – pause – 3 • The vehicle went out of Ready Mode: +12 V detected on the Brake Line.
10 – pause – 3 • The vehicle went out of Ready Mode: the Hood Pin-switch went to ground.
ON 2 sec.
• The Hood is up and the Hood Switch line went to ground. This is step one of
the Programming Centre procedure.
ON 3 sec. • First press of the
START button under Safe Start.
ON 4 sec. • Locking or unlocking a Door (with Door pulses configured to 4 sec.)
ON 25 sec.
• The Hood Pin-switch has been pressed twice: the Unit went into step 1 of the
Programming Centre procedure, and no Transmitter activity was detected for
20 seconds.
• Or the Unit went into step 1 of the Transmitter Programming procedure and
no activity was detected for a few seconds. The Unit has exited the
Transmitter Programming procedure.
Irregular
• If the unit gives irregular signals (1 to 10 flashes followed by a pause,
followed by further flashes), the system is playing back Start Failure Codes.
This occurs when the Hood Pin-switch is pressed three times.
Constant
flashes
up to 30 sec.
• Panic Mode was triggered.
