25
PARTS EXPLOSION & PARTS LIST
55
54
1
341
90
91
92
93 95 94 96 97 98
99
100
101 102
103 104 105
INFEED TABLE ASSEMBLY
Screw M6x12
Nut
Flange Nut
Flat Washer
Scale Plate
Infeed Table
Front Shaft
Handle Shaft
Hex Bolt
Lift Bracket 1
54
55
90
91
92
93
94
95
96
DESCRIPTION
P25-200H-1
P25-200H-54
P25-200H-55
P25-200H-90
P25-200H-91
P25-200H-92
P25-200H-93
P25-200H-94
P25-200H-95
P25-200H-96
KEY NO. MFG. PART NO. DESCRIPTION KEY NO. MFG. PART NO.
Spring Washer
Carriage Bolt
Lock Nut M8
Flat Washer
Carriage Bolt
Flat Washer
Knob
Hex Socket Head Screw
Locking Handle
Scale 97
98
99
100
101
102
103
104
105
341 P25-200H-97
P25-200H-98
P25-200H-99
P25-200H-100
P25-200H-101
P25-200H-102
P25-200H-103
P25-200H-104
P25-200H-105
P25-200H-341
NOTE: Please reference the Manufacturer’s Part Number when calling for Replacement Parts.
For Parts under Warranty, the Serial Number of your machine is required.
