Assembly Instructions Round Style 30x40x15
Industrial Round Style Building
18
Version 2.0
Please DO NOT return unit to store or dealer. For all questions or shortages please contact
Customer Service at: 800-447-7079 or 203-877-7070
MDM 30’ W x 40’L x 15’ H Portable Building
INVENTORY CHART
Part
Code Description Quantity
1 Interior & End Arch Top Ridge
Curve Tube 7
2 Interior Arch Curved Tube 10
2A Front Arch Curved Tube 2
2B Rear Arch Curved Tube 2
3 Sidewall Tube 6
3A Front Arch Sidewall Tube 2
3B Rear Arch Sidewall tube 2
3C Sidewall Wind Brace Support 2
3D Sidewall Wind Brace Support 2
4 Cross Rails (Roof Purlin &
Horizontal Tube) 30
5L Corner Base Flange – Left Side 2
5R Corner Base Flange – Right Side 2
6 Base flange Standing Legs Front &
Back Panel 4
7 Sidewall Base Flange 10
8 Back Panel Lower Standing Legs 2
9 Back Panel Upper Standing Legs 2
10 Upper Door Track 2
11 Lower Door Track 2
12 Front Wall Upper Beam 2
12A Front Panel Lower Beam 1
13 Back Panel Side Beam 2
13A Back Panel Middle Beam 1
14 Wind Brace Support 8
1414A Wind Brace Tube Clip 8
15 Tensioning Tube – Front Wall
Cover 2
15A Tensioning Tube – Back Wall
Cover 3
16 Door Dropping Tubes - Middle 6 Sets
17 Tensioning Tube – Main Cover 6 Sets
18 Tensioning Tube – Main Cover
Ends 2 Sets
19 Door Dropping Base Tube 1 set
20 Auger Anchor 18
21 Earth Anchors w/SS Tether 18
22 U-Bolt, Retaining Plate, Nuts 18
23 36” Drive Rod for Earth Anchors 1
24 10 mm x 85 mm Carriage Bolt 40
24A 10 mm x 75 mm Bolt 75
24B 10 mm x 85 mm Bolt 6
25 10 mm x 30 mm Bolt 28
26 10 mm x15 mm Bolt for Tie Down
Ratchet to Baseplates 28
27 Tie Down Ratchet 14
30 Main Cover - White 1
31 Fabric Cover Above Front Door 1
31A Fabric Front Wall Side Cover 2
32 Fabric Door Cover 1
33 Fabric Back/Rear Panel Cover 1
34 Tie down rope for Main Cover,
Front Wall Cover, Rear Wall
Cover, and Door 9
35 Elastic Bungee Connectors 200
36 Fabric Band for Tie Down Ratchet 14
37 Tensioning Tube Plastic Cap 10
38 Mechanical Door Components
39 Door Beam 1 Set
40 Earth Auger Wrench 1 Set
