Assembly Instructions
30x40x15 Round Style Portable Building With Single Door
12
Version 2.0
Please DO NOT return unit to store or dealer. For all questions or shortages please contact
Customer Service at: 800-447-7079 or 203-877-7070
Front Panel Covers - The Fabric Covers for the Front
Wall consist of three separate fabric pieces. Two Side
Panels (31A) are installed on either side of the door
frame opening. One of the panels has a cut out in it for
the Winching Mechanism. This should be installed on
the right hand side of the frame when facing from the
outside.
These pieces secure to the Front Panel Frame with
Bungee Cords (35) around the frame members at each
grommet. Start securing the side covers at the bottom
and work up towards the top. At the bottom of the panel,
use one of the ropes provided to lace the fabric to the
Lower Beam (15). A separate fabric cover, Cover above
Front Door Panel (31) is provided. Make certain to put
Bungee cords (35) along the horizontal frame members
as well as the perimeter of the panel.
Main Cover Edge Tie Off - Once both Front and Rear
Panel Covers are installed, the Main Cover Edge flap,
front and rear, should be tightened and tied off. Begin
by pulling the remaining Main Cover Material over the
Frame arch, so the rope pocket is over the edge of the
frame. Tie off the rope that goes through the rope
pocket on one side. The rope ties off to the loop that is
located on the Base Flange Corner (5L or 5R). Moving
to the other side, begin to pull the rope down. Hold the
rope in hand, and push down at the bottom of the rope
with a foot. Pull the rope tight, and tie off to the welded
hoop on the Base Plate. As you are pulling the edge
rope, it will be necessary to adjust the excess material
that will collect along the rope packet. Adjust the
material so that it is not bunched up and it does not pull
the main cover to one side or the other. Once the Front
is completed, repeat the process on the Rear flap of the
Main Cover.
