DVR User Manual
20
4.2.3 Spot
Step1: enter into system configuration live configurationSpot; refer to Fig 4-9:
Step2: select split mode: 1
×1and channel.
Step 3: dwell time: the time interval for a certain dwell
picture display switching to next dwell picture display
Step 4: while selecting the split mode, user can setup the
current picture group. Click button to setup the
previous channel groups of dwell picture, click
button to set the latter channel groups of dwell picture.
Fig 4-9 live configuration-Spot
4.2.4 Mask
User can setup private mask area on the live image picture, max threes areas.
Setup mask area: click Setting button and then enter
into live image. Next, press left mouse and drag mouse to
set mask area referring to the left picture. Click Apply
button to save the setting.
Delete mask area: select a certain mask area and left
click to delete that mask area. Then click Apply button to
save the setting.
Fig 4-10 live configuration-mask
