>>Stand-alone DVR User Manual
4
1.2 DVR appearance
Pic.4 Small case with button
Pic.5 Rear panel
1.3 Connector definition
1.3.1 Front panel button definition:
Power: Turn ON/OFF system. If system is closed by DVR software options, you should
press this button to start the system.
Menu: Enter system menu and return.
Record: Enter recording setting menu.
Files: Enter video file management menu.
Mode: witch quad ,signal picture and PIP display mode；Long time press as the
switching key of other mode, please refer to “Panel combination key definition”
PTZ: Enter PTZ control interface
Page Up: Turn up.
Page Down: Turn down.
Back Space
Up: Move up cursor.
