>>Stand-alone DVR User Manual
31
Set the host IP in “Local setting”，please refer to the chapter “Net set”.
Note：Set the “protocol” in “TCP” when connecting the DVR with WAN.
2） Port forwarding
Login the router and mapping following port:
80：WEB port
9101：order transport port
9301：Support Video-on-demand
9501：Support multi channels live picture transport
9601：Support remote talkback
9801：Support multi hosts connection backup
3） DDNS (Oray.net)
Take oray software for example: first login the webs
apply user
account and domain name.
There are tow method to login DVR via Oray domain name: One is setting the DDNS in host，
the other is setting the DDNS in router.
4）Remote login
Input the Domain name in IE browser, for example:
open
the surveillance window. You also can input the domain name in software to remote login the
host.
5）IE trusted site and security level setting
a) Open Internet Explorer and press “tool” －>“Internet options” to bob up the
following dialog box：
