Hired-Hand PowerTrak: Thrust Bearing Replacement User Manual
Page 2
Pulley Assembly
Load Block
Hall Effect Device
Spider Coupling
Delrin Bushing
Tensioning Springs
SpringCam
Limit Switch Actuator
Electrical
Enclosure
Disconnect
Screw
Load Nut
Thrust Bearing
Cable Locking
Screws
Upper Limit
Adjustment
Lower Limit
Adjustment
Upper Radial
Bearing
Aux. Connection
for Pulleys, or Cable
Motor Quick
