Warning – Hired-Hand Evolution Series 3000/3001: HUMIDITY SENSOR QUICK-CONNECT User Manual
Page 3
HIRED-HAND MFG., INC. • 1733 County Rd 68 • Bremen, Alabama 35033 · Phone 256-287-1000 • Fax 256-287-2000
Part No. 4802-5103 rev 5-08
Page 3 of 4
Figure 3: Wiring Diagram
Inset A
Example of
Evolution 3000/3001
PCB 169
NOTE: Wire Colors will
depend on Customer
Supplied Cable.
WARNING!
LOW VOLTAGE!
Keep Separate From
High Voltage Wires!
Inset A
