Warning – Hired-Hand Sens-O-Matic (Feed Hopper Switch) User Manual
Page 2
HIRED-HAND, INC.
• 1733 County Road 68 • Bremen, AL 35033 USA • Phone 256-287-1000 • Fax 256-287-2000
Manual Part No. 4802-0134 rev 5-07 Page
2 of 2
NOTES:
• It will require approximately 30 seconds for
the switch to cause the motor to engage.
• Instructions for trouble shooting are located
on the side label of the Sens-O-Matic™.
• Refer to supplement wiring diagram and/or
Hired-Hand Customer Support for optional
External Power Supply wiring.
Figure 2: Sens-O-Matic II™ Wiring Diagram
WARNING!
• Never plug the Sens-O-Matic™ into a standard
120 or 240 VAC outlet receptacle as serious
injury may result.
• Remove ALL Electrical Power from the feed fill
system before installation / wiring.
* Patent Number: 5,051,671
