Hired-Hand Polar Cool: Wall Mount Kit User Manual
Page 3
RollSeal, Inc. • 1751 County Road 68 • Bremen, Alabama 35033 • Phone 256-287-7000 • Fax 256-287-7010
Sheet Part No. 4801-5208 rev 1-07
Page 3 of 4
For the remainder of the installation, proceed to the PolarCool User Manual Part No. 4801-
5035 and/or to the Installation Manual for the PolarCool Remote Control Box Part No. 4801-5202.
8
Install the supplied Drain, Nut, Washer (0006-7010), and Drain Cap (0006-7011) in the
predrilled hole. See Figure 6.
7
Drain
(0006-7010)
Figure 6 – Drain Plug Assembly
Drain Cap
(0006-7011)
NOTE: The Drain Plug Assembly
should not be installed until
after the PolarCool is mounted.
Drain Nut
(Incl. w/Drain)
Drain Washer
(Incl. w/Drain)
