5
H81H3-TI2 USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket LGA1150 socket for Intel® 4
th
Generation Core
TM
Family Processors
2. DMIC Digital microphone header (For All-In-One Specification)
3. SPKR Speaker header (For All-In-One Specification)
4. F_AUDIO Front panel audio header
5. CLR_CMOS Clear CMOS jumper
6. CASE Case open header
7. PCIE1~2
Mini PCI Express slots (mini PCIE1 (full-card) supports extension cards with SATA
signal, USB signal and PCIE signal, and mini PCIE2 (half-card) supports extension
cards with PCIE signal & USB signal.)
8. F_USB Front panel USB 2.0 header
9. SATA_PWR SATA power connector
10. USB_CR 5-pin USB 2.0 header supports card reader or other USB 2.0 device
11. USB_CAM 5-pin USB 2.0 header supports camera or other USB 2.0 device
12. USB_TP 5-pin USB 2.0 header (yellow) supports touch panel or other USB 2.0 device
13. SATA2 Serial ATA 3Gb/s connector
14. SATA1 Serial ATA 6Gb/s connector
15. SYS_FAN 4-pin system cooling fan connector with smart fan function
16. CPU_FAN 4-pin CPU cooling fan connector with smart fan function
17. LDC Debug card header
18. CIR Consumer infrared header
19. F_PANEL Front panel switch/LED header
20. MON_SW LVDS brightness switch header (For All-In-One Specification)
21. LCD_SEL LCD panel select jumper (For All-In-One Specification)
22. LVDS LVDS connector (For All-In-One Specification)
23. DISP_BRT LVDS brightness control header (For All-In-One Specification)
24. LCD_PWR LVDS select jumper (For All-In-One Specification)
25. SODIMM 204-pin DDR3 SDRAM SO-DIMM
