Chapter 1
2
H81H3-TI2 USER MANUAL
Specifications
• Single-channel DDR3 memory architecture
• 1 x 204-pin DDR3 SO-DIMM socket supports up to 8 GB
• Supports DDR3 1600/1333/1066 MHz DDR3 SDRAM
Memory
• 2 x mini PCI Express slots
- mini PCIE1 (full-card) supports extension cards with SATA
signal, USB signal and PCIE signal.
- mini PCIE2 (half-card) supports extension cards with PCIE
signal & USB signal.
• Supported by Intel ® H81 Express Chipset
- 1 x Serial ATA 3Gb/s device
- 1 x Serial ATA 6Gb/s device
Expansion
Slots
Storage
• 1 x 19V DC_IN port
• 1 x HDMI port
• 1 x USB 2.0 port
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (1 x line-out, 1 x Microphone)
Rear Panel I/O
LAN • Realtek RTL8111G
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• Realtek ALC662VD
- 6 Channel High Definition Audio Codec
- Compliant with HD audio specification Audio
CPU
• Intel ® H81 Chipset
Chipset
• LGA1150 socket for Intel ® 4 th Generation Core TM Family
processors
• VRD 12.5
• 1 x 4-pin CPU_FAN connector with smart fan function
• 1 x 4-pin SYS_FAN connector with smart fan function
• 1 x LDC header
• 1 x 10-pin USB 2.0 header supports additional two USB 2.0 ports
- 1 x 5-pin USB 2.0 header supports camera or other USB 2.0
device
- 1 x 5-pin USB 2.0 header supports card reader or other USB
2.0 device
- 1 x 5-pin USB 2.0 header (yellow) supports touch panel or other
• 1 x Serial ATA 6Gb/s connector
• 1 x Serial ATA 3Gb/s connector
• 1 x Case open header
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x SATA power connector
Internal I/O
Connectors &
Headers
USB 2.0 device
