Chapter 3
Z97-MACHINE USER MANUAL
53
Main Advanced Chipset M.I.B. X Security Boot Exit
 Memory Configuration
Scroll to this item to view the following screen:
Memory RC Version (1.7.1.0)
This item shows the information of the memory RC version.
Memory Frequency (1333 MHz)
This item shows the information of the memory frequency.
Total Memory (2048 MB (DDR3))
This item shows the information of the total memory.
Press to return to the M.I.B. X Menu page.
The selection of Memory
Profiles which impacts
memory sizing behavior.
Memory Information
Memory RC Version 1.7.1.0
Memory Frequency 1333 Mhz
Total Memory 2048 MB (DDR3)
Memory Profiles Automatic
Memory Frequency 1333
Timing Default Current Target
tCL 9 9 9
tRCD 9 9 9
tRP 9 9 9
tRAS 24 24 24
NMode 1 1 0
tWR 10 10 10
tRFC 107 107 107
tWTR 5 5 5
tRRD 4 4 4
tRTP 5 5 5
tCWL 7 7 7
tREFI 5200 5200 5200
tFAW 20 20 20
tRC 33 33 33
tWRPRE 65000
tCPDED 65000
tPRPDEN 65000
OdtReadDelay 65000
tCKE 65000
tCCD 65000
tWPRE 65000
tRPRE 65000
tRDRD 65000
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
