Z97-MACHINE USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket LGA1150 socket for 4
th
and 5
th
Generation Intel ® Core
TM
processors
2. CPU_FAN1~2 4-pin CPU cooling fan connectors
3. DDR3_1~4 240-pin DDR3 Module slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SYS_FAN3 3-pin system cooling fan connector
6. USB3F Front panel USB 3.0 header
7. CLR_CMOS Clear CMOS jumper
8. NGFF M.2 slot for 2242/2260/2280 SATA or PCIE M.2 SSD
9. SATA3_1~4 Serial ATA 6Gb/s connectors
10. F_PANEL Front panel switch/LED header
11. SYS_FAN2 4-pin system cooling fan connector
12. CASE CASE open header
13. F_USB Front panel USB 2.0 header (supports EZ Charger)
14. SPK Speaker header
15. POST1~2 Debug POST LEDs
16. RST_BTN Reset switch
17. PWR_BTN Power on switch
18. F_AUDIO Front panel audio header
19. SPDIFO SPDIF out header
20. PCIE1~3 PCI Express Gen2 x1 slots
21. PCIEX16_1~2
* PCI Express Gen3 x16 slots for graphics interface
22. SYS_FAN1 4-pin system cooling fan connector
23. PWR_FAN 3-pin power cooling fan connector
24. ATX12V 8-pin +12V power connector
* The PCIEX16_2 slot supports PCI-E Gen 3.0 running at X8 mode and shares bandwidth with
the PCIEX16_1 slot.
* If installing two graphic cards into PCIEX16_1 and PCIEX16_2 slots, both two slots will run
at X8 mode.
