Page 28
Chapter 2
22
Z97-MACHINE USER MANUAL
No.
Components
No.
Components
1
CPU_FAN1~2
6
SPK
2
ATX_POWER
7
SYS_FAN1
3
SYS_FAN3
8
PWR_FAN
4
F_PANEL
9
ATX12V
5
SYS_FAN2
~
~
After you have installed the motherboard into a case, you can begin connecting the
motherboard components. Refer to the following:
2-4-7. Connecting Case Components
