A970M-A DELUXE USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket AMD Phenom TM
and later desktop processors (socket AM3+)
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~4 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. PWR_FAN
Power cooling fan connector
6. SATA1~5 Serial ATA 6Gb/s connectors
7. CLR_CMOS Clear CMOS jumper
8. F_PANEL Front panel switch/LED header
9. TPM Trusted Platform Module
10. CASE Case open header
11. SPK Speaker header
Front panel USB 2.0 headers
(F_USB1 supports EZ Charger function)
13. COM Serial port header
14. SYS_FAN System cooling fan connector
15. SPDIFO SPDIF out header
16. F_AUDIO Front panel audio header
17. PCI1~2 32-bit PCI add-on card slots
18. PCIE1~2 PCI Express x1 slots
19. PCIEX16_T PCI Express slot for graphics interface (runs at x4 mode)
20. PCIEX16 PCI Express slot for graphics interface
21. ATX12V 8-pin +12V power connector
12. F_USB1~3
