SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (IDE Mode)
Use this item to select SATA mode.
SATA Port1~5/eSATA
This motherboard supports five SATA channels and one eSATA, each channel allows
one SATA/eSATA device to be installed. Use these items to configure each device on
the SATA/eSATA channel.
Main Advanced Chipset M.I.B. X Boot Security Save & Exit
SATA Configuration
Serial-ATA Controller Enabled
SATA Mode IDE Mode
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 Not Present
SATA Port5 Not Present
eSATA Not Present
Press to return to the Advanced Menu page.
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Serial-ATA Controller (Enabled)
Use this item to select Serial-ATA controller options: Disabled, Compatible, En-
hanced.
Enable or Disable Serial ATA
