Specifications 29
6.0 Specifications
Operating Temp: +40° to +122°F (+4.4° to +50.0° C)
Storage Temperature: 0° to +185° F (–17.8° to +85°C)
Pressure Media:
Dry gaseous nitrogen, standard
Optional External Pressure Cylinder:
Capacity: 83.3 ft
3
N
2
@ 2,216 PSIG
Volume: 960 in 3
Rating: 2,216 psig
Test Pressure: 3,694 psig
Material: Aluminum
Regulated Pressure Gauge:
Size: 2-1/2 in. diameter
Range: 0–3,000 PSIG
Test Pressure: 4,500 PSIG
Accumulator and Output Pressure Gauges:
Size: 2-1/2 in. diameter
Range: 0–15,000 PSIG
Test Pressure: 22,500 PSIG
Over-pressure Rupture Disk:
Rating: 3,000 PSIG, nominal
Type: Stainless steel outer case
Pressure Media Filter:
Rating: 20 microns, Test Port and Input Port
40 microns, Test Port Hose
Type: Field replaceable
MPV Pressure and Vent Valves:
Type: Micro-metering with replaceable soft
seat
Material: Aluminum knobs, black anodized
All other parts 300 series stainless
steel
Internal Piping:
Tubing: 1/8 in. O.D., 0.035 in. wall thickness,
seamless Cu.
1/4 in. O.D., 0.035 and 0.065 in. wall
thickness, seamless 304 Stainless
Steel
Couplings: Stainless Steel, Swagelok type
Input Port:
Style: 1/4" 37° AN flare male
Pressure Rating: 2216 PSIG connected
Material: 300 series Stainless Steel
Test Port:
Pressure Rating: 10,000 PSIG.
Material: 300 series Stainless Steel
Vent Port:
Style: 1/4" 37° AN male
Pressure Rating: 10,000 PSIG
Material: 300 series Stainless Steel
Pressure Hoses:
Quantity Supplied: Two; one input, one output
Length: 4 ft. nominal, input hose
5 ft. nominal, output hose
Style: Input hose - Nylon-lined core tube
with synthetic fiber braid and polyester
cover. Fitted with CGA-580 (Brass)
nipple fitting on one end and 1/4" 37°
female AN swivel pressure fitting on
opposite end.
Output hose - Nylon-lined core tube
with synthetic fiber braid and
polyurethane cover. Fitted with
quick-disconnect plug (St Stl) on one
end and 1/4" 37° female AN swivel
tube coupling on the other.
Regulator:
Type: Single stage, self-venting, non-bleed
Pressure Rating: 3,000 PSIG max. inlet
Carrying Case PIN7000 only:
Type: Aluminum case with latched cover and
handle
Material thickness: 0.090 in., nominal
Finish: Enamel paint, textured finish
Color: Gray
Control Panel:
Material: Aluminum (5052-H32)
Thickness: 0.125 in
PIN7000 Finish: Gray enamel paint with black
silkscreen nomeclature
PIN7010 Finish: Dark Tan enamel paint with black
silkscreen nomenclature
Physical Specifications:
Weight: 46 lbs including all hoses and cables
PIN7000 Case Dim’s: 11" wide x 18" long x 11.5" high
PIN7010 Case Dim’s: 19" wide x 8.1" deep x 10.5" high
(Case Dimensions excluding front handles).
