Maintenance & Service

19

120 VAC input - PN 56679, 220 VAC input - PN 56682

Tools required:

Phillips screwdriver
Flat blade screwdriver (small)
11/32" Open end wrench or nutdriver

Removal of Pump Control Board:

1. Disconnect the power cord from the power source and line filter. Remove front panel from its enclosure

as described in Section 3.2.1 on page 6, and carefully set on a bench top.

2. Disconnect the wires from the terminal blocks located on the pump control board assembly.

NOTE: It may be helpful to mark ends of wire with location.

3. Loosen and remove the four nuts that hold the pump control board and remove the board.

Installation of Pump Control Board:

1. Position the new board over the four standoffs and install four nuts. Tighten the nuts until snug.
2. Connect the wires to the terminal blocks located on the pump control board assembly.

NOTE: Refer to the wiring diagram Figure 3-1 on page 6.

3. Install panel/chassis assembly in its enclosure as described in Section 3.2.1 on page 6.

3.3

MPV Valve Assembly (PN 65076) Parts List

The following table lists the component parts of the MPV.

* Part must be ordered seperately.

Ref Number

PN

Description

Quantity

1

54193

Valve body

1

2

54540

Housing, valve needle

1

3

59551

Valve needle

1

4

55896

Valve, seat

1

5

59045

Valve, needle seat

1

6

57889

Knob Insert

1

7

55570

Washer, backing

1

8

60837

Screw, mach-pan HD

1

9

60633

Retainer, packing

1

10

59387

Valve seat, stem

1

11

57482

Nut, valve needle housing

1

12

54401

Locknut

1

13

60202

Setscrew, hex housing

1

14

59245

Washer, flat

1

15

58079

*Knob

1

16

59322

*Setscrew

2

17

59383

Setscrew

2

18

55569

O-ring, Fluorocarbon (Viton) color black w/white dot

1

19

55552

O-ring, Fluorocarbon (Viton), color black w/white dot

1

20

*59731

Fitting, Male Connector 1/4 Tube

1

21

*59872

Fitting, Male Run Tee 1/4 Tube

1

Table 3-2. MPV Valve Assembly Parts List
