18 PIN7000/PIN7010 Operation and Maintenance Manual
3.2.18 Panel Mounted AC Power/EMI Line Filter (PN 58870), Removal and Installation
NOTE: See Figure 3-1 on page 6 for wiring diagram.
Tools required: Phillips screwdriver
1/4" Open end wrench or nutdriver
A/R soldering iron
A/R shrink sleeving (PN 60735)
A/R heat gun
1. Disconnect the power cord from the power source and line filter. Remove front panel from its enclosure
as described in Section 3.2.1 on page 6, and carefully set on a bench top.
2. Remove the three cable connectors from the line filter terminals.
NOTE: Some units may not have connectors and will require wire leads to be unsoldered.
3. Loosen and remove the line filter retaining nuts on the rear of panel.
NOTE: Some units may have screws on the front panel.
4. Remove the AC line filter.
5. To install a new line filter, reverse the order of steps 1 through 4. Connect (or solder) wires to the new
line filter as follows:
Green wire to terminal (E) Ground
White wire to terminal (N) Neutral
Black wire to terminal (P) Line
3.2.19 Power Switch (PN 60307), Removal and Installation
NOTE: See Figure 3-1 on page 6 for wiring diagram.
Tools required: Phillips screwdriver
Flat screwdriver
1/4" open end wrench or nutdriver
A/R soldering iron
A/R shrink sleeving (PN 60735)
A/R heat gun
Removal:
1. Disconnect the power cord from the power source and line filter. Remove front panel from its enclosure
as described in Section 3.2.1 on page 6, and carefully set on a bench top.
2. Remove the two black wires from pump control board TB2 terminals 1 and 2.
3. Loosen and remove the nut on the panel front and remove the switch from the panel rear.
4. Unsolder and remove the three wires from the switch terminals.
Installation:
1. Use shrink sleeving over wires/terminals for protection. Connect and solder the harness wires to the new
switch terminals per the following:
Terminal Function
Rear of Switch 1 On
2 Off
3 Momentary
Black wire to switch terminal 1
Black wire to switch terminal 2
Black jumper wire between switch terminals 1 & 3
2. Install the new switch through the rear of panel. Rotate switch so that the momentary position is toward
bottom of panel and secure it from the front of panel with the mounting nut.
3. Replace the two black wires to the pump control board TB2. Connect terminal 1 of switch to terminal 1
of TB2, and terminal 2 of switch to terminal 2 of TB2.
4. Install panel/chassis assembly in its enclosure as described in Section 3.2.1 on page 6.
3.2.20 Pump Control Board Assembly, Removal and Installation
NOTE: See Figure 3-1 on page 6 for wiring diagram.
