6
.
"DISPLAY" parameter to "MODIFY" in the "TRIP PT” Menu".
TRIP POINT VALUE RECALL: Recall the Trip Point values by pressing the
"DISPLAY" key in the run mode until the trip point prompts (triPl.H, tripl L, triP2.H or
triP2.L) are indicated. The Trip Point values are expressed in the current selected
pressure display units. Trip Point values are entered in Base Mode Units.
DISPLAY RECALLED TRIP VALUES
Display
Prompt
Trip Point Type Trip Band Type Remarks
TriP1.H Trip point 1 Trip Band 1 High Trip
TriP1.L -na- Trip Band 1 Low Trip
Not shown if “TRIP 1” set to
“OFF” In “TRIP PT” menu.
TriP2.H Trip Point 2 Trip Band 2 High Trip Not shown if “TRIP 2” set to
TriP2.L -na- Trip Band 2 Low Trip “OFF” In “TRIP PT” menu.
TO MODIFY A TRIP VALUE: Enter the trip value in the base mode units as described
below. The unit will automatically switch to the base mode units following entry and
prompt with the base units.
Activate the entry by pressing the ⇐ ⇐ ⇐ ⇐ (ZERO) key when the trip value is recalled on the
display. If currently in a converted unit display, the unit will automatically switch to the
base units. The display will prompt with the base units.
To modify the points utilize the arrow keys as follows:
• Each press of the ⇐ ⇐ ⇐ ⇐ right or left ⇒ ⇒ ⇒ ⇒ key moves the position of the digit to be
changed. The position is marked by the flashing of the selected digit.
• The selected digit is then incremented or decremented using the up ⇑ ⇑ ⇑ ⇑ / down ⇓ ⇓ ⇓ ⇓
keys.
• After entering the desired value press the “ENTER” key to accept this value. The
will switch to the base units, if not there already, and prompt with the base units.
• The trip modification can be aborted during entry by pressing the “CE” key.
