4
.
keys.
• After entering the desired value press the “ENTER” key to accept this value.
Step to the next set up using the down ⇓ key.
TRIP PT MENU TABLE
• The Lower Trip Band value (TRIP1.L and TRIP2.L) and associated
parameters (HYST1.L and HYST2.L) do not appear in the menu when the
“TRIP PT” Type is selected. The Lower value is automatically set for minus
full range in this mode
• The parameters in BOLD letters are the default values.
TRIP POINT SELECT MENU
PARAMETER CHOICES
DESCRIPTION
TRIP OFF
ON
When OFF, front panel trip indication can not be selected
and the Trip Menu is disabled.
Trip Option enabled
DISPLAY TRIP
ACCEPT Display indication for both trip point 1 and trip point 2.
Applies to trip band 1 only (trip band 2 set to OFF).
RECALL NONE
VIEW
MODIFY Can not view trip point status from front panel.
Can view trip point status from front panel only.
Can view and modify trip point status from front .
TRIP 1 OFF
ON Trip 1 is disabled.
Trip 1 is enabled.
TYPE 1 TRIP PT
BAND Trip 1 Point mode. High trip entry only.
Trip 1 Band mode. High and low trip entry.
TRIP 1 UNDER
OVER
Sets polarity of trip point 1 output to be active under
(below) trip point or in band.
Sets polarity of trip point 1 output to be active at and over
(above) trip point or out of band .
TRIP1.H ±XXXXX0 Upper trip point 1value
TRIP1.L ±XXXXX0 Lower trip point 1 value (applies to BAND type only)
HYST1.H DESCEND
ASCEND Hysteresis upper trip point 1 applies to descending data.
Hysteresis upper trip point 1 applies to ascending data.
HYST1.H ±XXXXX0 Hysteresis upper trip point 1 value.
HYST1.L DESCEND
ASCEND Hysteresis lower trip point 1 applies to descending data.
Hysteresis lower trip point 1 applies to ascending data.
HYST1.L ±XXXXX0 Hysteresis lower trip point 1 value.
TRIP 2 OFF
ON Trip 2 is disabled.
Trip 2 is enabled.
TYPE 2 TRIP PT
BAND Trip 2 Point mode. High trip entry only.
Trip 2 Band mode. High and low trip entry.
TRIP 2 UNDER
OVER
Sets polarity of trip point 2 output to active under (below)
trip point or in band.
Sets polarity of trip point 2 output to active at and over
(above) or out of band.
TRIP2.H ±XXXXX0 Upper trip point 2 value.
TRIP2.L ±XXXXX0 Lower trip point 2 value (applies to BAND type only).
HYST2.H DESCEND
ASCEND Hysteresis upper trip point 2 applies to descending data.
Hysteresis upper trip point 2 applies to ascending data.
