Condec DLR334 User Manual
Page 9
PAGE 9
74845
C
CmH
2
O
M
mmH
2
O4ΕC
V
VAC (SPECIAL)
D
inHgOΕC
N
PASCAL
E
Kg/cm
2
O
(SPARE)
F
FtseaH
2
O
P
PSI
G
inH
2
O60F
Q
(SPARE)
H
inH
2
O68F
R
(SPARE)
I
inH
2
O4ΕC
S
(SPARE)
J
MetrsH
2
O
T
TORR
par: one (1) character data field per Table V;
TABLE V
‘par’ ASSIGNMENT
DESCRIPTION
‘sp’
Standard Pressure
N
Net (pressure with Tare)
T
Tare
H
HP
P
Max
M
Min
F
Freeze
stat:
one (1) character data field;
I
= Invalid data
O
= Over range
U
= Under range
M
= Motion
C
= Center of zero 'Sp'
=
None of the above
10.0 STATUS RECALLED:
! COMMANDS:
PSR
= Pressure status (motion, etc).
MSR
= Unit/mode status
ISR
= Input status.
OSR
= Output status.
! Units/Mode status (MSR command)
DATA FORMAT:
LENGTH:
Fixed at 4 characters.
WHERE:
Unit1&2:
Two (2) character field. For character assignment refer to Table III &
Table IV.
par:
One (1) character field. For character assignment refer to Table VI.
TABLE VI
‘mode’ ASSIGNMENT
DESCRIPTION
N
Standard
C
Cal/config
