Brocade Enterprise Wireless LAN Antenna Specification Guide, Version 1.5 - Manual (Page 93)

Enterprise Wireless LAN Antenna Specification Guide 81
53-1001881-01
Chapter
10
AP 7131 Transmit Power
Configuring the AP 7131 Series Transmit Power
Professional installers must configure an AP 7131 series access point so it does not violate FCC
regulations pertaining to output transmit power.
This chapter describes how to adjust an AP 7131 series access point’s radio transmit power.
NOTE
Brocade assumes the AP 7131 series access point radio and power configuration activities
described in this chapter are conducted at the location that access point is actually installed and
deployed.
To define an AP 7131 series access point’s radio transmit power:
1. Complete the physical installation of the AP 7131 series access point following one of the
supported mounting options within either the AP 7131 Series Installation Guide or Product
Reference Guide. Both guides are available at
http://support.symbol.com/support/product/manuals.do.
An AP 7131 series access point can attach to a wall, mount under a suspended T Bar or above
a ceiling (plenum or attic) following the same installation instructions. Choose a mounting
option based on the physical environment of the coverage area. Do not mount the access point
in a location that has not been approved in a site survey.
2. Start a browser and enter the access point’s default static IP address for the WAN port
(10.1.1.1).
3. Initially log in using admin as the default Username and motorola as the default Password. Use
your new password if it has been updated from default.
If the default login is successful, the Change Admin Password window displays. Change the
password immediately to ensure secure access.
4. Select System Configuration > Quick Setup from the menu tree.
