106 Enterprise Wireless LAN Antenna Specification Guide
53-1001881-01
Japan TELEC Regulatory Domain 5.2 GHz Band
10
Patch Antenna Model
The following is the patch antenna model for 5.2 GHz:
Patch Antenna Maximum Conducted Transmit Power Settings
The following is a transmit power table (Japanese domain) per patch antenna in the 5 GHz band:
159 (157, 161)
161
165
Brocade Part Number
ML-2452-PTA3M3-036
20 MHZ
CHANNEL 40 MHZ
CHANNEL LEGACY OFDM RATES
(6,9,12,18,24,36,48,
54 MBPS) 802.11n
HT20 RATES
(MCS 0 MCS 15) 802.11n
HT40 RATES
(MCS 0 MCS 15)
36 21.0 21.0
38 (36, 40) 10.0
40 21.0 21.0
42 21.0 21.0
44 21.0 21.0
46 (44, 48) 10.0
48 21.0 21.0
52 21.0 21.0
54 (52, 56) 10.0
56 21.0 21.0
60 21.0 21.0
62 (60, 64) 10.0
64 21.0 21.0
100 20.0 20.0
102 (100, 104) 17.0
104 20.0 20.0
108 20.0 20.0
112 20.0 20.0
110 (108, 112) 17.0
116 20.0 20.0
20 MHZ
CHANNEL 40 MHZ
CHANNEL LEGACY OFDM RATES
(6,9,12,18,24,36,48,
54 MBPS) 802.11n
HT20 RATES
(MCS 0 MCS 15) 802.11n
HT40 RATES
(MCS 0 MCS 15)
