Enterprise Wireless LAN Antenna Specification Guide 123
53-1001881-01
Japan TELEC regulatory domain 2.4 GHz band
11
Indoor patch antenna model
The following is the indoor patch antenna model for 2.4 GHz:
Indoor patch antenna maximum conducted transmit power settings
The following is a transmit power table (Japanese domain) per Indoor Patch antenna in the 2.4 GHz
band:
Outdoor omni antenna model
The following is the outdoor omni antenna model for 2.4 GHz:
12 14.0 16.0 14.0
13 14.5 16.0 14.5
14
Brocade Part Number
ML-2499-SD3-01R
20 MHZ
CHANNEL 40 MHZ
CHANNEL LEGACY DSSS RATES
(1, 2, 5.5, 11 MBPS) LEGACY OFDM RATES
(6,9,12,18,24,36,48,5
4 MBPS) 802.11n HT20
RATES
(MCS 0 MCS 15) 802.11n HT40
RATES
(MCS 0 MCS15)
1 10.5 13.0 15.5
2 10.5 13.0 15.0
3 (1, 5) 10.5 13.0 15.0 18.5
4 (2, 6) 10.5 13.0 15.0 18.5
5 (3, 7) 10.5 13.0 15.0 18.5
6 (4, 8) 10.5 13.0 15.0 18.5
7 (5, 9) 10.5 13.0 15.0 18.5
8 (6, 10) 10.5 13.0 15.0 18.5
9 (7, 11) 10.5 13.0 15.0 18.5
10 10.5 13.0 15.0
11 10.5 13.0 15.0
12 10.5 13.0 15.0
13 10.5 13.0 15.0
14 11.5
Brocade Part Number
ML-2499-HPA3-01R
20 MHZ
CHANNEL 40 MHZ
CHANNEL LEGACY DSSS RATES
(1, 2, 5.5, 11 MBPS) LEGACY OFDM RATES
(6,9,12,18,24,36,48,5
4 MBPS) 802.11n HT20
RATES
(MCS 0 MCS 15) 802.11n HT40
RATES
(MCS 0 MCS15)
