24 Brocade VDX 6710-54 Hardware Reference Manual
53-1002390-08
LED activity interpretation
4
Optical media
port status
(one bicolor
LED [green
and amber] for
each 10 GbE
port) Off (no light) No light or signal carrier on the
media interface. Verify that the transceiver is installed
correctly and that the cable is
connected correctly.
Steady green Link is present. No action required.
Flickering green Online, frames flowing through
port. No action required.
Steady amber Carrier (light) is present, but not
online. No action required.
Fast blinking amber
(1/2 second
interval) Port is faulted. Change the transceiver or reset the
switch from the workstation.
Slow blinking amber
(2 second interval) Port disabled. Enable the port.
Optical and
copper media
port status
(one bicolor
LED [green
and amber] for
each 1 GbE
port) Off (no light) No light or signal carrier on the
media interface. Verify that the transceiver is installed
correctly and that the cable is
connected correctly.
Steady green Link is present. No action required.
Flickering green Online, frames flowing through
port. No action required.
Steady amber Carrier (light) is present, but not
online. No action required.
Fast blinking amber
(1/2 second
interval) Port is faulted. Change the transceiver or reset the
switch from the workstation.
Slow blinking amber
(2 second interval) Port is disabled. Enable the port.
TABLE 3 Port side LED patterns during normal operation (Continued)
LED name LED color Status of hardware Recommended action
