Page 26

8
Brocade VDX 6710-54 Hardware Reference Manual
53-1002390-08
Rack installation for a Brocade VDX 6710-54
2
4. Provide power to the switch as described in
“Providing power to the switch”
ATTENTION
Do not connect the switch to the network until the IP address is correctly set. For instructions on how
to set the IP address, see
“Setting the switch IP address”
Rack installation for a Brocade VDX 6710-54
Follow the installation instructions shipped with the appropriate rack mount kit:
•
To install the switch into a 4-post fixed-rail rack, refer to the latest version of the Fixed Rack
Mount Kit Installation Procedure, 53-1001274-0x.
•
To install the switch into a 2-post Telco rack, refer to the Flush Mount Rack Mount Kit
Installation Procedure, 53-1002127-0x.
Providing power to the switch
Perform the following steps to provide power to the Brocade VDX 6710-54.
1. Connect the power cords to both power supplies, and then to power sources on separate
circuits to protect against failure. Ensure that the power cords have a minimum service loop of
15.2 cm (6 in.) available and are routed to avoid stress.
2. Power on the Brocade VDX 6710-54 by turning both on/off switches to "I." The power supply
LEDs display amber until POST is complete, and then change to green. The switch usually
requires several minutes to boot and complete POST.
ATTENTION
Power is supplied to the switch as soon as the first power supply is connected and powered on.
Verifying operation
After you have powered on the system and POST is complete, verify that the switch is working
properly.
1. Verify that the power supply LEDs are solid green. See
for the location of
these LEDs.
2. Verify that the system power LED and the system status LED are solid green. See
