Brocade VDX 6710-54 Hardware Reference Manual
23
53-1002390-08
LED activity interpretation
4
FIGURE 4
LEDs on the non-port side of the Brocade VDX 6710-54
LED patterns
describes the port side LEDs and their behaviors.
1
Power supply and fan assembly #2 status LED
2
Power supply and fan assembly #1 status LED
TABLE 3
Port side LED patterns during normal operation
LED name
LED color
Status of hardware
Recommended action
System power
(one LED
[green])
Off (no light)
System is off or there is an
internal power supply failure.
Verify the system is powered on (power
supply switches to “l”), the power
cables are attached, and your power
source is live.
If the system power LED is not green,
the unit may be faulty.
Contact your switch service provider.
Steady green
System is on and power supplies
are functioning properly.
No action required.
System status
(one bicolor
LED [green
and amber])
Off (no light)
System is off or there is no
power.
Verify the system is on and has
completed booting.
Steady green
System is on and functioning
properly.
No action required.
Steady amber (for
more than 5
seconds)
A system fault has occurred
or the switch is in an
initialization state.
Check the management interface and
the error log for details on the cause of
the status.
Contact your switch service provider.
Blinking amber (for
more than 5
seconds)
A power supply or fan has
faulted, is absent, or is
unplugged or a system fault has
occurred.
Check the power supply and fan
assembly and the management
interface and the error log for details
on the cause of the status.
Contact your switch service provider.
Ethernet Link
(Management
and LOMM
[Remote
Lights Out]
port) (one LED
[green])
Off (no light)
There is no link.
No action required.
Steady green
Link is present.
No action required.
Ethernet
Activity
(Management
and LOMM
[Remote
Lights Out]
port) (one LED
[green])
Off (no light)
There is no activity.
No action required.
Blinking green
There is activity (traffic).
No action required.
