Utility Bench II Assembly Instructions 3
STEP 1
Install Casters
¡ Align the holes on one caster plate with
the threaded pegs on the bottom of the
Base Tube. Using the 3-way Wrench or a
9/16" wrench or socket, securely attach
the caster to the Base Tube.
¡ Repeat for the remaining three casters.
¡ Pop End Caps into the Base Tubes. Use
the mallet to set them into place.
STEP 2
Attach the Leg Assemblies to the Base Tubes
¡ Align one Leg Assembly above one Base Tube
Assembly with the casters on the bottom.
¡ Using the 1/4" Hex Key, secure the Leg Assembly
to the Base Tube with a Bench Cap Screw and
Curved Washer. Make sure the curve on the
washer matches the curve of the base tube.
¡ Repeat for the other Leg Assembly and Base Tube.
Bench Cap Screw
325-5166-00
Curved Washer
225-3522-00
Base Tube
with Caster Plate
End Cap
Caster
Leg Assembly
