Stuart Turner WC1 Toilet only Macerator - Manual (Page 9)

- 9 -
Cont ...
STEP 3 ADDITIONAL SANITARY CONNECTIONS
3.30 The unit is factory fitted with a cap, to seal the
additional
connections.
If the additional connection is to be used, unscrew
the 1½ " nut to remove the cap and seal.
3.31 The connection pipe must have a minimum fall of
1:33
(3 o ) into the unit.
3.32 This unit is supplied with an inlet connector ( E), to allow connection to 40 mm
(1½ ") diameter pipe.
3.33 Use the seal and nut with the inlet connector ( E), to connect to your inlet pipe.
Tighten to produce a watertight seal.
All pipe connector nuts should be hand tight to seal.
E
