Stuart Turner WC1 Toilet only Macerator User Manual
Page 5
- 5 -
Cont ...
2.11 Note 1: Only connect one sanitary device per inlet connection.
2.12 Note 2: The shower tray (lowest waste outlet) must be a minimum of
180 mm
above the base of the macerator, to ensure necessary drainage
and
must not contain a trap.
2 CONNECTIONS
See Note 1
180mm
See Note 2
Outlet - 22, 28 or 32 mm outside
diameter piping using flexible adaptor
OR
