- 13 -
Model WC1 WC2 WC3
Electrical
Volts/Ph/Frequency 230/1/50 230/1/50 230/1/50
Power consumed 500 Watts 500 Watts 500 Watts
Full load current 2.2 Amps 2.2 Amps 2.2 Amps
Rating Continuous Continuous Continuous
Max. No Starts per hour 60 60 60
Enclosure IPX4 IPX4 IPX4
Fuse Size 5 Amps 5 Amps 5 Amps
Mechanical
Max flow 90 litres/min 90 litres/min 90 litres/min
Max head (closed valve) 5.4 metres 5.4 metres 5.4 metres
Max liquid temperature 50 o C 50 o C 50 o C
Min liquid temperature 4 o C 4 o C 4 o C
Max ambient air temperature 40 o C 40 o C 40 o C
Max noise level 60 dB 60 dB 60 dB
Dimensions
Length 482 mm 482 mm 482 mm
Width 180 mm 180 mm 180 mm
Width behind pan 180 mm 180 mm 132 mm
Height (excluding flexible hoses) 278 mm 278 mm 278 mm
Weight (including accessories) 7.85 Kg 7.95 Kg 8.00 Kg
Connections
Clearance behind WC spigot 184 mm 184 mm 140 mm
WC 102 mm Dia. 102 mm Dia. 102 mm Dia.
Inlet(s) N/A 40 mm (1½ ") Dia. 40 mm (1½ ") Dia.
Outlet 32 mm (1¼ ") Dia. 32 mm (1¼ ") Dia. 32 mm (1¼ ") Dia.
Connecting cable 1.5 metres 1.5 metres 1.5 metres
7 TECHNICAL SPECIFICATION
Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.
