- 15 -
Cont ...
MI
NIM
U
M CLEARANCE
B
E
HIND W
C
SPIG
O
T
18
0
482
63
45
18
0
14
0
OUTLET ADAPTOR
MATERIAL: FLEXIBLE RUBBER
SUITABLE FOR PIPE SIZES
O 22mm O.D.
O 28mm O.D.
O 32mm O.D.(1 1/4")
WC CONNECTOR
SUITABLE FOR
O 102 mm
HORIZONTAL OUTLET
(BS EN 33/37 WC PANS)
CAN BE ORIENTATED BETWEEN
164 TO 196 CENTRE HEIGHT
INLET CONNECTOR (PUSH FIT)
SUITABLE FOR PIPE SIZE
O 40 mm (1 1/2")
O 41 > 43 mm O.D.
22
31 27
15
+
90
INLET CONNECTION
52
0
27
8
34 43 18
0
56
1,5 METRES
SUPPLY LEAD
REDUCING RING (PUSH FIT)
SUITABLE FOR PIPE SIZE
O 32mm (1 1/4")
WC3
