DRIVE STAND & MOTOR
BRC40
RTI
Part No.
Description Qty
Motor Gear Drive (Complete Assembly) Voltage: 110 or 220 VAC
110 volt unit has been tested and approved for 100 volt operation in
Japan 1
080-80130-00 Power Cord (110 Volt) 1
080-80002-00 Motor Mount 1
080-80002-01 Inner Column 1
080-80002-02 Outer Column 1
080-80003-03 Base 1
080-80003-01 Short Leg 2
080-80003-02 Long Leg 1
080-80000-21 Swivel Caster 3
080-80002-08 Locking Handle 1
080-80000-23 Accessory Box Support 1
080-80000-24 Bolt M6 x 1mm x 35mm Lg. 4
080-80000-25 Bolt M8 x 1.25mm x 60mm Lg. 3
080-80002-05 Bolt M10 x 1.50mm x 15mm Lg. 3
080-80003-04 Bolt Allen Socket Head M10 x 1.50mm x 25mm Lg. 3
080-80003-06 Plastic Cap 3
080-80000-29 Washer M6 8
080-80000-30 Washer M8 6
080-80000-31 Washer M10 4
080-80000-32 Nut M6 x 1.00mm 4
080-80000-33 Nut M8 x 1.25mm 3
080-80000-34 Nut M10 x 1.50mm 1
080-80002-07 Nut Square M10 x 1.50mm 6
Refer to next page for illustration of above components .
