Chapter 3 Detals of Functons
3.1 Functonal Overvew
This software opens communications with µR10000/µR20000/SR10000 (Referred to
hereinafter as the recorder in this manual.) units and acquires data at regular intervals.
Through the Monitor Server function, the acquired data is transferred to DAQLOGGER
or Remote Monitor via Ethernet. The following is a list of the features of each software
function.
Functons of the Software
• Entry of parameters used for communications with up to sixteen recorders.
When connecting via Ethernet: Address, user, password
For serial communications: Port, baud rate, parity, and address
• Displays information (model and number of channels) from the connected recorder
Opens communication with a recorder and automatically determines the model.
• Enter the following settings on each recorder.
• Upper/lower limit of span
*
• Decimal place
*
• Units
*
• Tag
*
• Color
* With automatic model determination, these device settings are automatically obtained.
• Entry of the data acquisition interval and port number
• Performing of the Test Execution
• The above communication parameters, device information from the recorder,
acquisition interval, and port numbers can be saved to a file
• Displays the status of the software.
Displays the client connection status and connected device communication status
• Displays software errors
• Runs as a monitor server
Compatible with the DAQLOGGER monitor server specifications.
