Page 12: Recorder settngs
2-3
IM WX1-08E
1
2
3
Index
Operat
ng Procedure
Recorder Settngs
Procedure
1.
Click the Recorder Settng tab or choose Vew > Recorder Settng from the
menu bar.
The Recorder Setting tab is displayed.
Click to display the Input Address
dialog box
Click to display a list box
for selecting a
communication port
Only enabled COM ports
(specified in serial port
settings) are displayed
2.
Enter the port and address.
Port:
Select the port to be used for the connection. Only the COM ports
turned ON in the serial setting tab are displayed.
For Seral Ports Set to COM1-COM9
Click an address to display the following dialog box.
Enter the address set on the device to which you wish to connect.
For Ports Set to Ether
Click an address to display the following dialog box.
Enter the IP address or host name, user name, and password of the device to
which you wish to connect.
2.2 Enterng Envronment Settngs
