12 IM 04L31A01-05E
Communication Commands
Communication commands are described in chapter 6, “Commands” in the DAQSTATION CX1000/CX2000
Communication Interface User’s Manual (IM04L31A01-17E) .
New Commands
Basic Setting Commands (Control)
• Event output setting
MN
Sets the event output setting method
Syntax MN p1
p1: Event output setting method (common or separate)
Query MN[ p1]?
Changed Commands
Setting Commands (Control)
• Event output setting
EO
Sets the event output
When the event output setting method is separate
Syntax EO p1,p2,p3,p4,p5
p1: Pattern number (1 to 30)
p2: Event kind (TimeEvent, PVEvent)
p3: Event number (1 to 16)
p4: Enable/disable relay output (Off, On)
p5: Relay number*
*: DO001 to DO006
DO101 to DO106
DO201 to DO206
RO001 to RO012 (expansion module)
SW001 to SW036 (internal switch)
DO001 to DO006, SW001 to SW018 on the CX1000.
Query EO?
When the event output setting method is Common
Syntax EO p1,p2,p3,p4
p1: Event kind (TimeEvent, PVEvent)
p2: Event number (1 to 16)
p3: Enable/disable relay output (Off, On)
p4: Relay number*
*: DO001 to DO006
DO101 to DO106
DO201 to DO206
RO001 to RO012 (expansion module)
SW001 to SW036 (internal switch)
DO001 to DO006, SW001 to SW018 on the CX1000.
Query EO?
