<2. Operation>
12
IM 12A01A02-12E
4th Edition : Sep. 3, 2013-00
2.3
Basic operation
When 2 sensor modules are installed, the Home display shows both sensor information at
one time, while the Main display will show the individual sensor information. If only one sensor
module is installed, the
is grayed out and disabled on the Main display. On the Home
display, pressing the 1st sensor (top) information or the 2nd sensor (bottom) information causes
the Main display of the selected sensor to appear.
Home Display
Main Display
6.35
Tag:FLXA21–PH
24.9
4mA
20mA
PH1
°C
24 mV
pH
Tag:FLXA21–PH
25.0 °C
19 mV
pH
10.38
10.38
Tag:FLXA21–PH
19
25.0
mV
4mA
20mA
PH1
°C
pH
