<10. General Specifications>
10-6
IM 01C50E01-01EN
10.5 Dimensions
 2-inch horizontal pipe mounting (Amplifier housing code 7)
82 *2 (3.23)
191 (7.52)
88 (3.46) 103 (4.06)
24
(0.94) 39
(1.54)
70 (2.76)
90
(3.54)
56 (2.20)
140
(5.51)
Terminal cover
Ground terminal
Mounting
bracket
Electrical
connection
2-inch pipe
(O. D. 60mm)
Electrical
connection
Integral
indicator
Ш1
10 (4.33)
Ш1
10 (4.33)
188 (7.40)
128 (5.04)
248
*1
(9.76)
40
(1.57)
15 (0.59)
35 (1.38)
Unit: mm (approx. inch)
*1: When amplifier housing code 8 is selected, the value is 307 mm (12.09 inch). When amplifier housing code 9 is selected,
the value is 187 mm (7.36 inch). In both cases, the figures are shown as A or B accordingly.
*2: When ampilfier housing code 8 or 9 is selected, the value is 81 mm.
A B
F1001.ai
 2-inch vertical pipe mounting (Amplifier housing code 7)
Unit: mm (approx. inch)
*1: When amplifier housing code 8 is selected, the value is 307 mm (12.09 inch). When amplifier housing code 9 is selected,
the value is 187 mm (7.36 inch). In both cases, the figures are shown as A or B accordingly.
*2: When ampilfier housing code 8 or 9 is selected, the value is 81 mm (3.19 inch).
A B
191 (7.52)
88 (3.46) 103 (4.06)
24
(0.94) 39
(1.54)
82 *2
(3.23)
140 (5.51)
98 (3.86)
204 (8.03)
110 (4.33)
Electrical connection
Mounting bracket
Electrical
connection
Integral
indicator
2-inch pipe
(O. D. 60mm)
Ground terminal
Terminal cover
248
*1
(9.76)
128 (5.04) Ш1
10 (4.33)
Ш1
10 (4.33) 35 (1.38)
104 (4.09) 107 (4.21)
61
(2.40)
F1002.ai
